TSKgel™ Amide-80 HPLC Column, 5 μm Particle Size, Sold by MilliporeSigma™ Supelco™
For the analysis of saccharides, glycans, oligosaccarides, peptides, and polar compounds from natural products.
| Catalog Number | Length (Metric) | Diameter (Metric) |
|---|---|---|
| 820010 | 10 cm | 1 mm |
Catalog number 820010
View Price:Sign InSign in to see your account pricing. Need an account? Register with us today.
Length (Metric):
10 cm
Diameter (Metric):
1 mm
- Columns are packed with 3, 5, or 10 micron spherical silica particles covalently bonded with carbamoyl groups
- Amide stationary phase provides a unique selectivity under regular normal phase conditions, or in the hydrophilic interaction mode of chromatography
- Target applications include the analysis of saccharides, glycans, oligosaccarides, peptides, and polar compounds from natural products
- Unique advantages of Amide-80 phase for saccharide analysis include a novel hydrogen bonding retention mechanism between hydroxyl groups of the sample and the carbamoyl group in the stationary phase
- Stationary phase does not react with reducing sugars
- Can be used at elevated temperatures (≤ 80°C) to prevent peak splitting of carbohydrates
- High efficiency, 3 micron columns offer shorter analysis time and enhanced sensitivity for LC-MS applications
- Shipped in 85% acetonitrile, 15% water
TSKgel is a registered trademark of Tosoh Corporation
Specifications
Diameter (Metric)1 mm
Length (Metric)10 cm
Max. Pressure60 bar
Particle Size5 μm
pH2 to 7.5
Pore Size100 Å
Solvents0-100% Organic Solvent
Surface Area450 m2/g
Temperature10°C to 80°C
USP TypeL68
Stationary PhaseCarbamoyl
Product LineTSKgel
Shipping ConditionShipped in 85% Acetonitrile, 15% Water
MatrixCarbamoyl Phase/Silica Particle Platform
MaterialStainless Steel Hardware
TechniqueHILIC
